Rear Camber Bushing Kit

IPD - 112394

Item Number
112394
Brand
IPD
Position
Rear
Brand Classification
AMP
Units Per Car
1
Specifications
KIT CONTAINS TWO BUSHINGS
Warranty
One Year Parts Warranty
Product Group
Performance parts
OE References
Genuine Volvo - 30748889

Product Description

IPD’s rear camber bushing allows you to adjust for excessive rear camber that can cause premature tire wear and poor braking performance.

Typically excessive negative rear camber occurs when lowering a vehicle via sport springs though some stock vehicles can also require adjustment. Since there is no factory provision for rear camber adjustment IPD has developed an eccentric offset bushing that provides up to 1.5 degree of camber adjustment (negative or positive) to help correct your alignment problems.

The bushing must be pressed into the chassis in a particular orientation to realize the benefits of the design. Installation should be performed by an experienced technician who is familiar with this process and the appropriate tools required to complete it.

Not only can this help alleviate tire wear issues, it can also restore lost braking performance by increasing the contact surface of the tire to the road. Bests results are often obtained in combination with a set of IPD adjustable toe rods to deal with the thrust issue that is also common to lowered vehicles.

XC90 front wheel drive models beginning with chassis 292343-

Product Fitment Notes & Potential Issues

This kit fits models as follows:

  • 2001-2009 S60 w/ All Wheel Drive
  • 2001-2007 V70 w/ All Wheel Drive
  • 2001-2007 XC70
  • 2004-2006 S80 w/ All Wheel Drive
  • 2003-2006 XC90 w/ All Wheel Drive
  • 2006 XC90 w/ Front Wheel Drive with chassis number 292343 and higher.
  • 2007-2014 XC90 (All)

Chassis number is the last 6 digits of your vehicle's VIN.

These bushings are a direct replacement for the stock bushings and can re-use the original hardware.

Vehicle Fitment Guide

YearMakeModelTrimChassisBodystyleEngineFuelsysDriveTransmission
2009VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2008VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2007VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2007VOLVOS60RP24 DR SEDANB5254T4ME7AWDM66 AWD
2007VOLVOS60RP24 DR SEDANB5254T4ME7AWDTF-80SC AWD
2006VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2006VOLVOS60RP24 DR SEDANB5254T4ME7AWDM66 AWD
2006VOLVOS60RP24 DR SEDANB5254T4ME7AWDTF-80SC AWD
2005VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2005VOLVOS60RP24 DR SEDANB5254T4ME7AWDAW55-5X AWD
2005VOLVOS60RP24 DR SEDANB5254T4ME7AWDM66 AWD
2004VOLVOS602.5TP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2004VOLVOS60RP24 DR SEDANB5254T4ME7AWDAW55-5X AWD
2004VOLVOS60RP24 DR SEDANB5254T4ME7AWDM66 AWD
2003VOLVOS602.5T AWDP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2002VOLVOS602.4TP24 DR SEDANB5244T3ME7AWDAW55-5X AWD
2006VOLVOS80TURBOP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2005VOLVOS80TURBOP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2004VOLVOS80TURBOP24 DR SEDANB5254T2ME7AWDAW55-5X AWD
2007VOLVOV702.5T AWDP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2007VOLVOV70RP25 DR WAGONB5254T4ME7AWDM66 AWD
2007VOLVOV70RP25 DR WAGONB5254T4ME7AWDTF-80SC AWD
2006VOLVOV702.5T AWDP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2006VOLVOV70RP25 DR WAGONB5254T4ME7AWDM66 AWD
2006VOLVOV70RP25 DR WAGONB5254T4ME7AWDTF-80SC AWD
2005VOLVOV702.5T AWDP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2005VOLVOV70RP25 DR WAGONB5254T4ME7AWDAW55-5X AWD
2005VOLVOV70RP25 DR WAGONB5254T4ME7AWDM66 AWD
2004VOLVOV702.5T AWDP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2004VOLVOV70RP25 DR WAGONB5254T4ME7AWDAW55-5X AWD
2004VOLVOV70RP25 DR WAGONB5254T4ME7AWDM66 AWD
2003VOLVOV702.5T AWDP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2003VOLVOV70XCP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2002VOLVOV702.4T AWDP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2002VOLVOV70XCP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2001VOLVOV702.4T AWDP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2001VOLVOV70XCP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2007VOLVOXC702.5TP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2006VOLVOXC702.5TP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2005VOLVOXC702.5TP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2004VOLVOXC702.5TP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2003VOLVOXC702.5TP25 DR WAGONB5254T2ME7AWDAW55-5X AWD
2002VOLVOXC702.4TP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2001VOLVOXC702.4TP25 DR WAGONB5244T3ME7AWDAW55-5X AWD
2014VOLVOXC903.2P25 DR SUVB6324S5DENSOFWDTF-80SC
2014VOLVOXC903.2P25 DR SUVB6324S5DENSOAWDTF-80SC AWD
2013VOLVOXC903.2P25 DR SUVB6324S5DENSOFWDTF-80SC
2013VOLVOXC903.2P25 DR SUVB6324S5DENSOAWDTF-80SC AWD
2012VOLVOXC903.2P25 DR SUVB6324S5DENSOFWDTF-80SC
2012VOLVOXC903.2P25 DR SUVB6324S5DENSOAWDTF-80SC AWD
2011VOLVOXC903.2P25 DR SUVB6324S5DENSOFWDTF-80SC
2011VOLVOXC903.2P25 DR SUVB6324S5DENSOAWDTF-80SC AWD
2011VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2010VOLVOXC903.2P25 DR SUVB6324SDENSOFWDTF-80SC
2010VOLVOXC903.2P25 DR SUVB6324SDENSOAWDTF-80SC AWD
2010VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2009VOLVOXC903.2P25 DR SUVB6324SDENSOFWDTF-80SC
2009VOLVOXC903.2P25 DR SUVB6324SDENSOAWDTF-80SC AWD
2009VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2008VOLVOXC903.2P25 DR SUVB6324SDENSOFWDTF-80SC
2008VOLVOXC903.2P25 DR SUVB6324SDENSOAWDTF-80SC AWD
2008VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2007VOLVOXC902.5TP25 DR SUVB5254T2ME7AWDAW55-5X AWD
2007VOLVOXC902.5TP25 DR SUVB5254T2ME7FWDAW55-5X SN
2007VOLVOXC903.2P25 DR SUVB6324SDENSOFWDTF-80SC
2007VOLVOXC903.2P25 DR SUVB6324SDENSOAWDTF-80SC AWD
2007VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2006VOLVOXC902.5TP25 DR SUVB5254T2ME7AWDAW55-5X AWD
2006VOLVOXC902.5TP25 DR SUVB5254T2ME7FWDAW55-5X SN
2006VOLVOXC90T6P25 DR SUVB6294TME7AWD4T65 AWD
2006VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2005VOLVOXC902.5TP25 DR SUVB5254T2ME7AWDAW55-5X AWD
2005VOLVOXC90T6P25 DR SUVB6294TME7AWD4T65 AWD
2005VOLVOXC90V8P25 DR SUVB8444SDENSOAWDTF-80SC AWD
2004VOLVOXC902.5TP25 DR SUVB5254T2ME7AWDAW55-5X AWD
2004VOLVOXC90T6P25 DR SUVB6294TME7AWD4T65 AWD
2003VOLVOXC902.5TP25 DR SUVB5254T2ME7AWDAW55-5X AWD
2003VOLVOXC90T6P25 DR SUVB6294TME7AWD4T65 AWD
